ErgoDynamic Forearm Crutches by FDI

Lightest crutch in the world with an integrated shock absorber.

ErgoDynamic is exactly what the name says, DYNAMIC! It is FDI’s premier design featuring an integrated shock absorber system that softens each step to avoid shock to the hands, wrists and shoulders. The unique shock absorber is integrated into the upper shaft and utilizes an exclusive in-handle linkage system offering smooth, silent operation throughout its 1.26 inches (2.5cm) travel. This one of kind design provides greater feedback and control while providing positive forward momentum to the user. ErgoDynamic is available in 3 shock absorber weight range options.

Features:

Integrated shock absorber system softens each steps and eliminates shock to hands

Operates smoothly and silently throughout its 1.6” (2.5cm) of travel

Provides positive (rebound) energy for improved mobility

Available in 3 spring rate/weight options

Soft replaceable forearm pad

Each crutch weighs only 1.32 lbs (600g)

Ultra-soft replaceable grips with easy push button release

Height selection locking device with safety clip

Epoxy coated 5086 aluminum legs for maximum strength and long term durability

Full length aluminum backbone design for maximum strength

Flexible crutch tip design maximizes surface contact at angle

Maximum user weight is 286 lbs (130kg)

Complies to CE (EU Directive 93/42/EEC) and European Norm ISO 11334-1

Latex Free

Specifications:

User Height Range: 4'7" - 6'8" (140 - 204 cm)

Weight per crutch: 1.32 lbs (600 g)

Maximum user weight: 286 lbs (130 kg)

Height - Grip to floor range: 28.4 - 39.0" (72 – 99 cm)

Height Adjustment Increments: 12 x 1" (2.5 cm)

Distance between handle and cuff top: 9.6" (24.5 cm)

Maximum shock absorbing range: 1.26" (3.2cm)

Spring rate/weights range options: 3 (S, M, L) *

Leg tube diameter (upper/lower O.D.): 0.87"/0.75" (22/19mm)

Available in 3 Spring Rate/Weight options:

(S) up to 154lbs (70kg)

(M) 132 - 198lbs (60-90kg)

(L) over 176lbs (80kg)

Available Colors: Black and White

Available Parts & Accessories:

FDI Replacement Grips (Item# 515-GB)

FDI Replacement Crutch Tips (Item# 515-GB)

FDI Tripod Crutch Tip (Item# 515-TP)

FDI Safety Clip Height Adjuster (Item# 515-LP)

FDI Forearm Strap with easy release (Item# 515-FS)
